Teltonika 5G COMBO MOBILE/GNSS SMA ANTENNA

Teltonika 5G COMBO MOBILE/GNSS SMA ANTENNA

$208.99
$208.99 $200.00
Technical Data Mounting type M6 Screw or Adhesive Enclosure material PC/PC+ABS UV resistant ✓ Cable length 3000 mm Weight 450 g Operating temperature -40 °C ~ +80 °C Operating humidity ≤ 90 % Ingress Protection Rating IP67 RoHS compliant ✓ 5G MOBILE MIMO ANTENNA Frequency range 600 ~ 960, 1427 ~ 2700, 3300 ~ 4200, 4400 ~ 5000 MHz Polarisation Linear Radiation pattern type Omni-directional Gain ≤ 4 dBi V.S.W.R ≤ 2.5 Impedance 50 Ω Connector type and count 4 x SMA Male Cable type 4 x LMR100 GNSS ANTENNA Frequency range 1559 ~ 1610, 1164 ~ 1189 MHz Polarisation RHCP Radiation pattern type Directional Gain ≤ 2 dBi LNA Gain 17 ± 2 dB LNA noise figure ≤ 2 dB V.S.W.R ≤ 2 Impedance 50 Ω Supply voltage 3 ~ 5 VDC Current consumption 15 mA Connector type and count 1 x SMA Male Cable type 1 x LMR100
Teltonika 5G COMBO MOBILE/GNSS SMA ANTENNA
Teltonika

Teltonika 5G COMBO MOBILE/GNSS SMA ANTENNA

★ ★ ★ ★ ☆ 4.8 (1,234 reviews)
$208.99
In Stock Ships within 1 business day
Estimated delivery by state
NSW 1–2 business days
VIC 1–2 business days
ACT 1–2 business days
QLD 2–3 business days
SA 2–4 business days
WA 3–5 business days
TAS 3–5 business days
NT 4–6 business days

Dispatched from Sydney. Express available at checkout.

Technical Data Mounting type M6 Screw or Adhesive Enclosure material PC/PC+ABS UV resistant ✓ Cable length 3000 mm Weight 450 g Operating temperature -40 °C ~ +80 °C Operating humidity ≤ 90 % Ingress Protection...
Wi-Fi
802.11ax
Speed
1 Gbps WAN
Ports
8x Gigabit
Buy Now
Free Shipping
Orders over $100
2 Year Warranty
Full coverage
30-Day Returns
No questions
Technical Specifications
Technical Data Mounting type M6 Screw or Adhesive Enclosure material PC/PC+ABS UV resistant ✓ Cable length 3000 mm Weight 450 g Operating temperature -40 °C ~ +80 °C Operating humidity ≤ 90 % Ingress Protection Rating IP67 RoHS compliant ✓ 5G MOBILE MIMO ANTENNA Frequency range 600 ~ 960, 1427 ~ 2700, 3300 ~ 4200, 4400 ~ 5000 MHz Polarisation Linear Radiation pattern type Omni-directional Gain ≤ 4 dBi V.S.W.R ≤ 2.5 Impedance 50 Ω Connector type and count 4 x SMA Male Cable type 4 x LMR100 GNSS ANTENNA Frequency range 1559 ~ 1610, 1164 ~ 1189 MHz Polarisation RHCP Radiation pattern type Directional Gain ≤ 2 dBi LNA Gain 17 ± 2 dB LNA noise figure ≤ 2 dB V.S.W.R ≤ 2 Impedance 50 Ω Supply voltage 3 ~ 5 VDC Current consumption 15 mA Connector type and count 1 x SMA Male Cable type 1 x LMR100
